Representing Surfaces in Reverse Engineering Using Analogue Signals

Name: Representing Surfaces in Reverse Engineering Using Analogue Signals
Brand: LAP Lambert Academic Publishing
SKU: 9783659977794
Price: 48.42 EUR
Availability: InStock

Autor: Ibrahim Eldeeb

Jazyk:

Väzba: Brožovaná

Vydavateľ: LAP Lambert Academic Publishing

Dostupnosť: Skladom u dodávateľa

Odosielame za 5-8 dní

48.42 €

Reverse engineering is the process of reconstructing a computer model for physical objects based on...

Informácie o knihe

Autor

Ibrahim Eldeeb

Jazyk

Angličtina

Väzba

Kniha - Brožovaná

Vydalo

2016

Stránok

148

EAN

9783659977794

Enbook ID

15545829

Vydavateľ

LAP Lambert Academic Publishing

Hmotnosť

238

Rozmery

150 x 220 x 9

Kompletný popis

Reverse engineering is the process of reconstructing a computer model for physical objects based on 3D data points captured from the surface of the object. This work presents a low end and extremely cost effective technique for representing free-form surfaces of physical objects in a CAD model. An analogue signal was used to acquire the free-form surface data unlike conventional methods like laser scanners or Coordinate Measurement Machines (CMM). The examined surface was scanned using a Linear Variable Differential Transducer, (LVDT) as position sensor for measuring the data from the surface of the object. The analogue signal of the LVDT was acquired through a data acquisition system in a continuous fashion to PC. Solid-Works CAD/CAM software was used to obtain the free-form surface from the acquired 3D data using spline technique.
