Circuit simulation is widely used for the design of circuits, both discrete and integrated. Device modeling is an impor tant aspect of circuit simulation since it is the link between the physical device and the sim ulate d device. Curren tly available circuit simulation programs provide a variety of built-in models. Many circuit designers use these built-in models whereas some incorporate new models in the circuit sim ulation programs. Understanding device modeling with particular emphasis on circuit simulation will be helpful in utilizing the built-in models more efficiently as well as in implementing new models. SPICE is used as a vehicle since it is the most widely used circuit sim ulation program. How ever, some issues are addressed which are not directly appli cable to SPICE but are applicable to circuit simulation in general. These discussions are useful for modifying SPICE and for understanding other simulation programs. The gen eric version 2G. 6 is used as a reference for SPICE, although numerous different versions exist with different modifications. This book describes field effect transistor models commonly used in a variety of circuit sim ulation pro grams. Understanding of the basic device physics and some familiarity with device modeling is assumed. Derivation of the model equations is not included. ( SPICE is a circuit sim ulation program available from EECS Industrial Support Office, 461 Cory Hall, University of Cali fornia, Berkeley, CA 94720. ) Acknowledgements I wish to express my gratitude to Valid Logic Systems, Inc.
